Instant pricing calculator
| No. | LED constitution | 3 x 3 m | 3 x 2 m | 6 x 3 m | 6 x 2 m | ||||
| 1 | SMD1415 | Kinglight copper LED | Kinglight copper LED | Kinglight copper LED | Kinglight copper LED | ||||
| Module Specifications | |||||||||
| 1 | Pixel Pitch(mm) | 2.604 | 2.604 | 2.604 | 2.604 | ||||
| 2 | Module Size(mm) | W | H | W | H | W | H | W | H |
| 500 | 62.5 | 500 | 62.5 | 500 | 62.5 | 500 | 62.5 | ||
| 3 | Module Resolution(pixels) | W | H | W | H | W | H | W | H |
| 192 | 24 | 6 x 2 m | 24 | 192 | 24 | 192 | 24 | ||
| 4 | Module Pixles(pixels) | 4,609 | #VALUE! | 4,609 | 4,609 | ||||
| 5 | Pixel Density(pixels/m2) | 1,47,475 | 1,47,475 | 1,47,475 | 1,47,475 | ||||
| Screen Parameters | |||||||||
| 1 | Screen Size(m) | W | H | W | H | W | H | W | H |
| 3 | 3 | 3 | 2 | 6 | 3 | 6 | 2 | ||
| 2 | Screen Area(m2) | 9.00 | 6.00 | 18.00 | 12.00 | ||||
| 3 | Module Quantity (pcs) | 6 | 48 | 6 | 32 | 12 | 48 | 12 | 32 |
| 4 | Module Quantity of a screen (pcs) | 288 | 192 | 576 | 384 | ||||
| 5 | Screen resolution | 1152 | 1152 | #VALUE! | 768 | 2304 | 1152 | 2304 | 768 |
| 6 | Brightness | 600cd/㎡ | |||||||
| 7 | Driving Method | 1/24 scan | |||||||
| 8 | View Angle | 140° | |||||||
| 9 | Min. Viewing Distance | ≥2.5 meter | |||||||
| 10 | Gray scale | 65536×65536×65536 | |||||||
| 11 | Colors | 281 trillion | |||||||
| 12 | Refresh rate | ≥3840Hz | |||||||
| 13 | Input Voltage | DC24V/36V | |||||||
| 14 | weight | 16kg/sqm | |||||||
| 16 | MTBF | >10,000 hours | |||||||
| 17 | Life span | ≥100,000 hours | |||||||
| 18 | IP rating(Front/Rear) | IP65/IP41 | |||||||
| 19 | Temperature-operating | ﹣20℃～50℃ | |||||||
| 20 | Humidity-operating | 10%～90% | |||||||
| 21 | Controlling system | Nova | |||||||
